Example of using the REST API to retrieve menu details - Documentation for Remedy Action Request System 20.08

To retrieve all the information in a menu, such as labels and values, use GetMenu and ExpandMenu endpoints. The GetMenu and ExpandMenu endpoints help to perform faster design-level integration between a Remedy application and a third-party application without using Remedy Developer Studio.

For example, assume you have a menu that displays continents in the world. When you select a continent, another menu asks you to select a specific country. You can use the GetMenu endpoint to retrieve metadata of the Continent menu. Later you can use the ExpandMenu endpoint to retrieve details of the Continent menu.

• Before using the GetMenu endpoint, you must use the getField endpoint to retrieve field metadata.
• Before using the ExpandMenu endpoint, you must use the GetMenu endpoint to retrieve menu metadata for a menu.

The GetMenu API takes the name of the menu and the menu criteria as input and returns the menu properties, such as the menu content. The following table lists details about using this GET operation to retrieve menu metadata.

Date →<Current server date> X-Frame-Options →SAMEORIGIN Content-Security-Policy →frame-ancestors 'self' X-Content-Type-Options →nosniff X-XSS-Protection →1; mode=block Status →200 X-AR-TR-Core-Id →evANniBcScqSEwE2LSxZIB X-AR-TR-Counter →1 Content-Type →application/json Cache-Control →no-store Content-Length →406

{ "menu_name": "<Menu Name>", "refresh_code": "<Refresh Code>", "help_text": "<Help text for the menu>", "owner": "<Owner Username>", "last_changed_by": "<Last change by Username>", "menu_type": "QUERY", "change_history": [ { "changed_by": "<UserName>", "changed_time": "<Timestamp>", "text": "<Text>" }, ... ], "properties": [ { "<key>": "<value>" }, ... ], "menu_information": { "form_name": "<Form Name>", "server_name": "<Server Name>", "label_fields": [ "<field id1>", "<field id2>" ], "value_field_id": "<field id>", "sort_on_label": "<TRUE/FALSE>", "qualification_string": "<Qualification string>", "qualification_current_fields" : [ "<current_field1>", "<current_field2>" ], "qualification_keywords" : [ "<keyword1>", "<keyword2>" ], "sample_form_name": "", "sample_server_name": "" }, "_links": { "self": [ { "href": "<Get Menu url>" } ] } }

{ "menu_name": "<Menu Name>", "refresh_code": "<Refresh Code>", "help_text": "<Help text for the menu>", "owner": "<Owner Username>", "last_changed_by": "<Last change by Username>", "menu_type": "QUERY", "change_history": [ { "changed_by": "<UserName>", "changed_time": "<Timestamp>", "text": "<Text>" }, ... ], "properties": [ { "<key>": "<value>" }, ... ], "menu_information": { "server_name": "<Server Name>", "label_index": "<Label Index>", "value_index": "<Value Index>", "sql_command": "<Sql query>" }, "_links": { "self": [ { "href": "<Get Menu url>" } ] } }

{ "menu_name": "<Menu Name>", "refresh_code": "<Refresh Code>", "help_text": "<Help text for the menu>", "owner": "<Owner Username>", "last_changed_by": "<Last change by Username>", "menu_type": "QUERY", "change_history": [ { "changed_by": "<UserName>", "changed_time": "<Timestamp>", "text": "<Text>" }, ... ], "properties": [ { "<key>": "<value>" }, ... ], "menu_information": { "menu_items": [ { "label": "", "value": "" } ] }, "_links": { "self": [ { "href": "<Get Menu url>" } ] } }

{ "menu_name": "<Menu Name>", "refresh_code": "<Refresh Code>", "help_text": "<Help text for the menu>", "owner": "<Owner Username>", "last_changed_by": "<Last change by Username>", "menu_type": "QUERY", "change_history": [ { "changed_by": "<UserName>", "changed_time": "<Timestamp>", "text": "<Text>" }, ... ], "properties": [ { "<key>": "<value>" }, ... ], "menu_information": { "server_name": "<Server Name>", "name_type": "<Name Type>", "value_format": "<Value Format>", "schema_type": "<Schema Type>", "include_hidden_form": "TRUE/FALSE" }, "_links": { "self": [ { "href": "<Get Menu url>" } ] } }

{ "menu_name": "<Menu Name>", "refresh_code": "<Refresh Code>", "help_text": "<Help text for the menu>", "owner": "<Owner Username>", "last_changed_by": "<Last change by Username>", "menu_type": "QUERY", "change_history": [ { "changed_by": "<UserName>", "changed_time": "<Timestamp>", "text": "<Text>" }, ... ], "properties": [ { "<key>": "<value>" }, ... ], "menu_information": { "location": "<location 1/2>", "file_name": "<file name>" }, "_links": { "self": [ { "href": "<Get Menu url>" } ] } }

Expand Menu

After retrieving the menu metadata by using the GetMenu endpoint, use the ExpandMenu endpoint to retrieve the menu details. For example, when you retrieve metadata of the Continent menu, use the ExpandMenu endpoint to retrieve details, such as list of countries in each continent.

The ExpandMenu API takes the name of the menu as a path parameter and returns the expanded menu content in response. The following table lists details about this operation.

{ "name": "Company_Details" }

Example of response header for the expand menu request

Date →<Current server date> X-Frame-Options →SAMEORIGIN Content-Security-Policy →frame-ancestors 'self' X-Content-Type-Options →nosniff X-XSS-Protection →1; mode=block Status →200 X-AR-TR-Core-Id →8Z0KEnv6Q2i-luK-JWYNAw X-AR-TR-Counter →1 Content-Type →application/json Cache-Control →no-store Transfer-Encoding →chunked

Example of JSON for the expand menu request

To evaluate a qualification, you must specify the qualification_substitute_info key in the query menu.

{ "name": "TestQueryMenu_dfb88", "qualification_substitute_info": { "form_name": "TestForm_dfb88", "field_values": { "536870915": 100 }, "keyword_values": { "USER": "Demo" } }, "max_entries": 5, "total_count": true }

{ "items": [ { "type": "Value", "label": "Data10", "value": "180" }, { "type": "Value", "label": "Data2", "value": "100" }, { "type": "Value", "label": "Data4", "value": "120" }, { "type": "Value", "label": "Data5", "value": "130" }, { "type": "Value", "label": "Data6", "value": "140" } ], "total_count": 7 }

{ "items": [ { "type": "Value", "label": "Assigned To", "value": "Assigned To" }, { "type": "Value", "label": "Create Date", "value": "Create Date" }, { "type": "Value", "label": "Last Modified By", "value": "Last Modified By" }, { "type": "Value", "label": "Modified Date", "value": "Modified Date" }, { "type": "Value", "label": "Qualification", "value": "Qualification" }, { "type": "Value", "label": "Request ID", "value": "Request ID" }, { "type": "Value", "label": "Short Description", "value": "Short Description" }, { "type": "Value", "label": "Status", "value": "Status" }, { "type": "SubMenu", "label": "Status History", "content": [ { "type": "Value", "label": "Status History", "value": "Status History" }, { "type": "SubMenu", "label": "TIME", "content": [ { "type": "Value", "label": "New", "value": "" }, { "type": "Value", "label": "Assigned", "value": "" }, { "type": "Value", "label": "Fixed", "value": "" }, { type": "Value", "label": "Rejected", "value": "" }, { "type": "Value", "label": "Closed", "value": "" } ] }, { "type": "SubMenu", "label": "USER", "content": [ { "type": "Value", "label": "New", "value": "" }, { "type": "Value", "label": "Assigned", "value": "" }, { "type": "Value", "label": "Fixed", "value": "" }, { "type": "Value", "label": "Rejected", "value": "" }, { "type": "Value", "label": "Closed", "value": "" } ] } ] }, { "type": "Value", "label": "Submitter", "value": "Submitter" } ] }
