To display information about the initialization parameters for active CICS regions, including the suffix of each region’s system initialization table (SIT), issue the following command:

CREVIEW [target]

where target is the specific or generic name of a target CICS region.

The following figure is displayed:

ddmmmyyyy hh:mm:ss ------ MAINVIEW WINDOW INTERFACE (Vv.r.mm) ---------------- COMMAND ===> CURR WIN ===> 1 ALT WIN ===> W1 =CREVIEW==========(BCVWBALL=*=======)ddmmmyyyy=hh:mm:ss====MVCICS===D===16============================= CMD Region CICS SMF APPLID SYS Start Start --- --- -------- -------- S U F F I X E S --- ---- --- --- --- --- Name Release ID ID Date Time SIT MCT PLTPI PLTSD RST SRT CLT FCT PDIR TCT TST XLT BCVDA70C 0700 SJSC BCVDA70C A70C 14AUG2018 08:49 6$ MA PP 1$ BCVDA71C 0710 SJSC BCVDA71C A71C 14AUG2018 07:13 6$ MA PP 1$ BCVDA72C 0720 SJSC BCVDA72C A72C 14AUG2018 05:02 6$ MA DFHPLTPP DFHPLTPP 1$

Usage notes

The CREVIEW view can be used as the starting point for reviewing a region’s SIT parameters. Use the hyperlinks that are described in the following table to display specific SIT parameters and their values.

If you place the cursor on a CICS region name in the CREVIEW view and press Enter, the EZCREV view is displayed:

ddmmmyyyy hh:mm:ss ------ MAINVIEW WINDOW INTERFACE (Vv.r.mm) ---------------- COMMAND ===> SCROLL ===> CSR CURR WIN ===> 1 ALT WIN ===> W1 =CREVIEW==EZCREV==(BCVDVPC==*=======)ddmmmyyyy==hh:mm:ss====MVCICS===D====1= CICS SIT Menu Target CICS region -> BCVCD720 .Applications +----------------------+ .Fields A-F .Autoinstall | Place cursor on | .Fields G-R .Basic Mapping Support | menu item and | .Fields S-Z .CICS WEB Interface | press ENTER | .Data Interchange +----------------------+ .Database .Dispatcher Functions .Long Fields .System Startup .DL/I .Miscellaneous .System Termination .Dump .Monitoring .TCPIP / SSL .Extended Recovery .RDO File Control .Temporary Storage .File .Security .Terminal and LU .ISC and Multiregion .Signon .Timer .JAVA .Special Tracing .Trace .Journaling .Standard Tracing .Transaction Backout .Keystroke Retrieval .Storage Management .Transient Data .Loading Programs .Supervisor Calls .VTAM

From EZCREV, you can select:

• a category, such as Application

  When you hyperlink from a category field, the detail view that contains that type of SIT parameters is displayed.

• an alphabetic grouping, such as Fields A-F

When you hyperlink from an alphabetic field, an alphabetic list of SIT parameter names is displayed, as shown below.

ddmmmyyyy hh:mm:ss ------ MAINVIEW WINDOW INTERFACE (Vv.r.mm) ---------------- COMMAND ===> SCROLL ===> PAGE CURR WIN ===> 1 ALT WIN ===> >W1 =CREVIEW==CREVDX===BCVDS67C=*========ddmmmyyyy==hh:mm:ss====MVCICS===D====1 Target BCVCD680 A-F... ADI.......... CHKSTRM... CSDBUFNI. DFLTUSER... ENCRYPTION G-R... AIBRIDGE..... CHKSTSK... CSDDISP.. DIP........ EODI...... S-Z... AICONS....... CICSSVC... CSDDSN... DISMACP.... ESMEXITS.. AIEXIT....... CILOCK.... CSDFRLOG. DOCCODEPAGE FCT....... AILDELAY..... CLINTCP... CSDINTEG. DSALIM..... FCQRONLY.. AIQMAX....... CLSDSTP... CSDJID... DSHIPIDL... FEPI...... AIRDELAY..... CLT....... CSDLSRNO. DSHIPINT... FLDSEP.... AKPFREQ...... CMDPROT... CSDRECOV. DSRTPGM.... FLDSTRT... APPLID....... CMDSEC.... CSDRLS... DTRPGM..... FORCEQR... AUTCONN...... CONFDATA.. CSDSTRNO. DTRTRAN.... FSSTAFF... AUTODST...... CONFTXT... CWAKEY... DUMP....... FTIMEOUT.. AUTORESETTIME CPSMCONN.. DAE...... DUMPDS..... AUXTR........ CRLPROFILE DATFORM.. DUMPSW..... AUXTRSW...... CSDACC.... DB2CONN.. DURETRY.... BMS.......... CSDBKUP... DBCTLCON. EDSALIM.... BRMAXKEEPTIME CSDBUFND.. DEBUGTOOL EJBROLEPFX.

Note

This view is the same view that is displayed when you hyperlink from the SIT Suffix field of the CREVIEW view.

From CREVDn (or any of the other alphabetic lists), you can select a specific SIT parameter and hyperlink to the detail view that contains that parameter.

The G-R... hyperlink displays the CREVDY view, which contains an alphabetical listing of SIT parameters starting with the letters G to R inclusive.

The S-Z... hyperlink displays the CREVDZ view, which contains an alphabetical listing of SIT parameters starting with the letters S to Z inclusive.

CREVDn detail views

To display the system initialization table (SIT) parameters for a CICS region, issue the following command:

CREVDn target

where target is the name of the target CICS region, and n identifies a set of SIT parameters as follows:

The following figure shows a sample CREVD1 view.

ddmmmyyyy hh:mm:ss ----------- INFORMATION DISPLAY --------------------------- COMMAND ===> SCROLL ===> PAGE CURR WIN ===> 1 ALT WIN ===> W1 =CREVD1============CICSPRD1=*========ddmmmyyyy==hh:mm:ss====MVCICS===D====1 Target... BCVCD680 Parameter Value O Description --------- -------- - ------------------------------ Application Considerations CMDPROT.. YES Command Protection Option CMDSEC... ASIS Global Command Security CWAKEY... CICS Y CWA Storage Key DISMACP.. YES Disable MACRO programming INITPARM. 2F682048 Y Initial Parm Data LGNMSG... NO VTAM Logon Data Option OPERTIM.. 120 WTO Timeout Interval TCTUAKEY. CICS Y TCT User Area Key TCTUALOC. BELOW TCT User Area Location

Usage notes

• Each CREVDn detail view presents one or more logical groupings of SIT parameters. As a group, the CREVDn views provide the complete list of SIT parameters.

• Each CREVDn detail view shows the name of the SIT parameter, its current value, and whether the original value was overridden by a SYSPARM or SYSIN change.

• Some CREVDn detail views have default hyperlink fields defined that provide links from:

  • A storage address to the DUMP view of the associated data

    An example of this type of hyperlink is the INITPARM value on the CREVDA view.

  • A parameter whose data is too long to display to CREVD9, the Long Data view

    An example of this type of hyperlink is the GMTEXT parameter on the CREVD3 view.
